JKC Goldline Type Flush Valve Spindle – 32mm (JKC-1083)

Goldline Type Flush Valve Spindle – Stop the Drip Without a Full Replacement

A leaking or hard-to-operate Goldline concealed flush valve usually doesn’t need a full replacement – just a worn spindle. The JKC Emart Goldline Type Flush Valve Spindle (32mm, JKC-1083) is a precision brass-and-rubber replacement built to restore smooth, reliable 180-degree flush action in Goldline-style concealed flush valves.

Specifications

• Drive Head: 9mm, 20-tooth splined head
• Operation: 180-degree turn
• Shaft Length: 76mm
• Total Length: 109mm
• Upper Thread Diameter: 27mm
• Lower Thread Diameter: 32mm
• Base Cap Diameter: 27mm
• Material: Brass and rubber

Easy Installation & Use

Installation is a straightforward four-step swap: turn off the water supply feeding the flush valve, unscrew and remove the old spindle, thread in the new JKC spindle by hand, then replace the cover and test the flush action. No plumber tools are required for a hand-tight installation – just make sure the O-ring seats fully before testing for leaks.

Benefits of the Goldline Type Flush Valve Spindle

• Helps Stop Leaks at the Source: Replaces only the worn spindle instead of the entire flush valve body
• Precision Fit: Dimensions matched to the technical reference drawing, not estimated
• Durable Brass Core: Corrosion-resistant construction built for years of daily flushing
• Cost-Effective Replacement: A simple part swap instead of a full flush valve replacement
• Rubber-Sealed Construction: O-ring and piston seal designed to resist leaks at the joint

Who Can Benefit?

Homeowners dealing with a running or dripping Goldline flush valve who want a quick self-install fix.
Plumbers looking for a dimension-verified compatible spindle for Goldline-type service calls.
Property and facility managers maintaining standardized Goldline fittings across multiple units.

About JKC Emart

JKC Emart is a Vadodara, Gujarat-based manufacturer and seller of bathroom fittings and plumbing spare parts, producing precision-matched compatible replacement parts for Jaguar-style, Cera-style, Goldline-style, and other sanitaryware systems. Browse the full range at jkcemart.in.

A Simple Fix for a Common Problem

A leaking Goldline flush valve doesn’t have to mean a plumber visit or a full replacement. This precision-matched spindle restores smooth, reliable flush performance with a straightforward self-install swap.
